Replacement transmitter for an existing Lodar 9 Series wireless system — a transmitter is the handheld unit and is not a standalone product. It pairs with a matching receiver on the same series and function count.
The 6 Function Lodar Stainless IP Transmitter (92S06TX-8) is the stainless steel Industrial Pro (IP) handheld for a Lodar 9 Series system, sending 6 functions of control to the receiver on your equipment. It has a stainless steel keypad, carries an IP 65 rating, runs on 4× AAA batteries, and reaches a 150 ft (45 m) operating range.
Will this transmitter work with my receiver?
Match three things: the series (9 Series), the function count (6), and the receiver it was coded to. Transmitters and receivers are paired on the same RF band, so replace a 9 Series transmitter with a 9 Series transmitter. If you are replacing a lost or damaged handset, confirm the receiver model before ordering.
- 6 functions of control
- Stainless IP transmitter — stainless steel keypad
- IP 65 rated, operates 13°F to 104°F (-10°C to 40°C)
- Powered by 4× AAA batteries
- 150 ft (45 m) operating range
- Lodar SKU 92S06TX-8
Match the trailing code. Lodar 9 Series transmitters and receivers carry a trailing match number. Check the unit you are replacing: no number means -8, the most common code we carry, and some systems use -3. If your existing system or part is coded anything other than -8, contact us so we send the correct unit.
This is a replacement part — it goes on the 6-function 9 Series wireless system. See the complete 6 Function Stainless Steel IP Wireless Control System or 6 Function IP Wireless Control System or 6 Function Standard Wireless Control System. Pair it with the matching 6 Function receiver on the same system.
